ACO StormBrixx Range

Stormwater attenuation and infiltration/soakaway crates

ACO StormBrixx is a unique and patented plastic geocellular stormwater management system for attenuation and soakaway (infiltration) usage.

Its versatile design allows the system to be used in configurations and applications across all construction environments as a standalone solution or as part of an integrated sustainable urban drainage (SuDS) scheme.

The patented brickbonding and cross bonding feature provides a strong, long term installation and also helps to improve the construction speed of the tank.

ACO StormBrixx simplifies delivery, site logistics and installation as a result of its stackable design. For each delivery of StormBrixx, up to 4 loads of competitor product may be required, making StormBrixx approximately 75% more efficient in delivery.

The range consists of StormBrixx SD (standard duty) and StormBrixx HD (heavy duty) stormwater management systems.

NEW StormBrixx HD900

ACO is pleased to introduce our latest solution within the Stormbrixx family, the StormBrixx HD900. Enjoying the full benefits of the brick bonding and cross bonding design of the Stormbrixx range, the StormBrixx HD900 achieves greater strength than any of our existing models. Find details of the new product down below and within the downloadable StormBrixx data sheet.

Stormbrixx - 1 Minute Overview Video

This concise video compares the new StormBrixx SD attenuation and soakaway crate solution with the existing StormBrixx HD, examining key features including:

• Simplified handling and logistics
• Structural integrity
• Access and maintenance

NEW! StormBrixx Configurator

Designing and specifying attenuation or infiltration tanks for flood mitigation and sustainable drainage systems (SuDS) is now easier than ever with ACO's new StormBrixx Configurator. The software allows users to design a StormBrixx tank in a step-by-step manner and produce a full bill of materials.

• Launch software
• Read launch article

Featured Downloads

Login or register to download

StormBrixx Brochure

Detailed information on ACO's StormBrixx unique and patented plastic geocellular stormwater management system.

Download

StormBrixx DataSheet

Reviewing and comparing both the StormBrixx SD and HD and HD900 systems including the new half layer for the SD.

Download

Access and maintenance

The whole system, including all the extremities can be inspected and maintained from just a few access points thanks to the open cell structure.

Simplified handling and logistics

The stackable nestled design of each body piece optimises logistics and installation costs by reducing deliveries and storage space needed on site.

Structural integrity

The patented brickbonding and cross bonding feature enables strong, long term installation and improved construction speed of the tank.

Countless configurations

StormBrixx attenuation and soakaway crates offer countless configurations, for flexibility in design and construction to fit any site.

• Find out more about StormBrixx configurations

StormBrixx SD offers a versatile solution that enjoys the benefits of the innovative design of the range. It is suitable for use in a wide range of construction applications.

Specs

• High porosity of 97%
• Layer Height 914mm
• 350KN/m2 Short term vertical compressive strength
• 70KN/m2 Short term lateral compressive strength

Key Benefits

• 347 cubic metre capacity per truck delivery
• Includes access plates for CCTV and jetting equipment
• Half Layer Available

Certification

• MFPA certification
• Complies with BS EN 17152-1

StormBrixx HD GF - is a heavy-duty system that offers man access for the more comprehensive maintenance requirements of Local Authorities and water companies.

Specs

• Porosity of 95%
• Layer Height 612mm
• 455kN/m2 Short term vertical compressive strength
• 95KN/m2 Short term lateral compressive strength

Key Benefits

• 309 cubic metre capacity per truck delivery
• Available with Max Access Unit
• 309 cubic metre capacity per truck delivery

Certification

• DIBt Certification
• Complies with BS EN 17152-1

StormBrixx HD900 offers incredible strength while enjoying the same benefits as StormBrixx SD. It is an ideal solution for more demanding installation and loading requirements such as HGV traffic. ​​

Specs

• High porosity of 97%
• Layer Height 920mm
• 605KN/m2 Short term vertical compressive strength
• 120KN/m2 Short term lateral compressive strength

Key Benefits

• 347 cubic metre capacity per truck delivery
• Includes access plates for CCTV and jetting equipment
• Half Layer Available

Certification

• DIBt and MFPA certification
• Complies with BS EN 17152-1

ACO have created a comparison guide, designed to be a useful tool for specifying stormwater solutions. This gives a more holistic look at the range of systems in the market including permeable paving, large pipes, concrete tanks and geocellular crates, such as ACO StormBrixx.

The guide looks at legislation and key criteria such as: structural strength, design flexibility, logistics and maintenance, in order to help in specifying the right stormwater solution for the project.

Featured Downloads

Login or register to download

Specifying Stormwater Solutions

A comparison guide of different stormwater solutions against key criteria of: structural strength, design flexibility, logistics and maintenance

Download

StormBrixx Accesories

StormBrixx SD Half body 314090

StormBrixx SD Side panel 314091

StormBrixx SD Top cover 314092

StormBrixx SD Horizontal pipe connector 27262

StormBrixx SD Layer connector 314093

StormBrixx SD Remote Access plate 314075

StormBrixx HD Half body 314020

StormBrixx HD Side panel 314021

StormBrixx HD Top cover 314022

StormBrixx HD Horizontal pipe connector 27105

StormBrixx HD Layer connector 314023

StormBrixx HD Remote access module 27034

StormBrixx HD Man access unit

StormBrixx SD & HD Horizontal pipe connector

StormBrixx SD & HD Vertical connector for inspection point 27018

StormBrixx SD & HD Access chamber 314056

StormBrixx SD & HD Access chamber vented 314055

StormBrixx SD & HD Inspection point 314045

StormBrixx SD & HD Inspection-rising shaft 314038

StormBrixx SD & HD Protection fleece 27041

StormBrixx SD & HD ACOWrap 27042

StormBrixx SD & HD Infiltration geotextile 27038

ACO StormBrixx has a range of flow control systems that work with it to regulate storm water flow before it discharges into the watercourse or sewer networks. ACO Q-Brake flow controls and ACO Q-Plate orifice plates are capable of regulating any flow for surface water applications and can be used in conjunction with retention and attenuation systems, such as ACO StormBrixx, as an integrated sustainable urban drainage (SuDS) scheme.
